Fotek Inductive Proximity Sensor PL-05N-V

5 mm, NPN NO, 10–30 VDC, ABS plastic, IP67

Technical specifications

• Sensing type: Inductive sensor, which detects metal objects using electromagnetic fields.
• Sensing distance: 5 mm.
• Output type: NPN (Negative-Positive-Negative) with a Normally Open (NO) configuration. This means the output signal switches to a low or ground state when a metal object is detected.
• Operating voltage: 10–30 VDC.
• Response frequency: 800Hz, for fast detection in high-speed environments.
• Body material: ABS plastic.
• Dimensions: 35mm (L) x 17mm (W) x 17mm (H).
• Protection rating: IP67, making it resistant to dust and water.
• Operating temperature: –20°C to +80°C.
• Wiring: The sensor is a 3-wire system with standard color codes for DC power and output.
  • Brown wire: +V (Positive)
  • Blue wire: 0V (GND / Negative)
  • Black wire: Signal Out

Applications

The PL-05N-V is a versatile component that is widely used for:

• Industrial automation: For detecting the presence or absence of a component on a conveyor belt or assembly line.
• CNC machinery: As a limit switch to determine the end of travel for a moving part.
• Robotics: For position control and object detection.
• Counting: For counting items passing a specific point in a process.
• Safety interlocks: To ensure machinery only operates when certain conditions are met.
