Fotek PL-05NB Sensor Inductive Proximity Switch

Fotek PL-05NB Inductive Proximity Switch Sensor NPN 5mm Sensing Distance, FOTEK Proximity Switch PL-05NB Sensor NPN

The FOTEK PL-05NB inductive proximity switch is an NPN, normally closed (NC) sensor with a 5mm sensing distance, suitable for industrial automation and 3D printing applications. It features short-circuit and reverse connection protection, an LED indicator, and an IP67 protection rating.

Specifications

• Model	FOTEK PL-05NB  (also known as PL-05N2)
  Sensing Distance	5 mm ± 10%
  Output Type	NPN, Normal Close (NC)
  Supply Voltage	DC 10-30V
  Control Output	<300 mA
  Response Frequency	DC: 0.5kHz
  Protection	Reverse connection, surge absorption, load short-circuit protection
  IP Rating	IP67 (IEC specification)
  Material	ABS plastic housing
  Wiring	3-wire (Brown: Positive, Blue: Negative, Black: Signal Output)
