Fotek PL-05NS Proximity Sensor
The Fotek PL-05NS Sensor is an inductive proximity switch with NPN, normally open (NO) output, designed to detect metal objects without physical contact. It operates on a DC voltage supply and is built for industrial applications.
Key Specifications
| Sensor Type | Inductive |
| Output Method | NPN, normally open (NO), 3-wire |
| Sensing Distance | 5 mm |
| Operating Voltage | 10V - 30V DC |
| Response Frequency | Up to 800 Hz |
| Load Current | ≤ 150 mA |
| Protection Circuit | Short circuit and polarity reversed protection |
| Protection Class | IP67 (dust and water resistant) |
| Operating Temperature | -25°C to +80°C |
| Housing Material | Red reinforced plastic (ABS resin) |
| Body Dimension | 30.0 x 16.4 x 10.5 mm (L x W x H) |
Features
- Reliable Detection: Provides accurate and reliable non-contact detection of metal objects.
- Durable Construction: Features a high solid compact structure with an IP67 rating, suitable for harsh industrial environments.
- Integrated Protection: Includes built-in short circuit and reverse polarity protection for enhanced durability and safety.
- Operating Indicator: All models come with an operating indicator light, making adjustment and operation easy.
- Versatile Applications: Commonly used in industrial automation, CNC machines, conveyor systems, and robotics for position sensing and object counting.
