PM-A0004-IV Analog output module

Description:

The PM-A0004-IV is a 4-channel analog output module. Each channel supports both voltage (V) and current (I) output modes, allowing flexible integration into various industrial control systems, including motion control, process automation, and data acquisition.

Key Features
Channels: 4 analog outputs
Output Types:
– Voltage: 0–5 V, 0–10 V, ±5 V, ±10 V
– Current: 0–20 mA, 4–20 mA
Resolution: 16-bit D/A conversion
Accuracy: ±0.1% (typical)
Isolation: Optical isolation between channels and system bus
Status Indicators: LEDs for power and channel activity
Connection: Screw terminals or detachable terminal blocks
Mounting: DIN-rail (EN 50022 standard 35 mm)
