Panasonic PM-F45-P U-shaped (fork-style) Micro Photoelectric Sensor

The Panasonic PM-F45-P is a U-shaped, or fork-style, micro photoelectric sensor designed for object detection in tight spaces. It operates using a through-beam sensing method, with the emitter and receiver housed in a single unit.

Key specifications

• Sensing method: Through-beam (U-shaped/fork-style)
• Detection range: 6 mm
• Minimum detectable object: An opaque object of 0.8 x 1.2 mm or larger.
• Sensing light: Infrared LED (855 nm wavelength).
• Supply voltage: 5 to 24 V DC.
• Output type: PNP open-collector transistor, with dual Light-ON and Dark-ON outputs.
• Maximum output current: 50 mA.
• Response time: 20 µs (Light Received) and 80 µs (Light Interrupted).
• Indicator: Orange LED lights up when light is received.
• Protection rating: IP64, offering dust-tight protection and protection against splashing water.
• Connections: 1 meter (3.28 ft) pre-wired cable.
