Panasonic Sunx PM-L24-R Photoelectric Sensor, Micro Sensor

Panasonic Sunx Photoelectric Sensor PM-L24-R Through-beam, U-Shaped / L-Type, 5-24V DC Supply Voltage, 5mm Sensing Distance, Infrared Light, NPN - Dark-ON/Light-ON - Selectable, LED Indicator, Chassis Mount,
Panasonic Sunx Micro Sensor PM-L24-R

Specification/Additional Details

• Sensor Type : Through-Beam
• Brand : Panasonic / Sunx
• Model : PM-L24-R
• Power supply : 5V to 24V DC
• Light source : Infrared
• Detection distance : 5mm

• Operating mode : Dark ON, Light ON Selectable

• Output type : NPN

• Display type : LED indicator

• Connection method : Pre-wired

• Cable length : 1m

• Mounting Type : Chassis Mount
