Panasonic PM-L45-P U-shaped (fork) Micro Photoelectric Sensor

PM-L45-P Photoelectric Sensor, Through-beam, Fixed 6 mm Sensing range, PNP open-collector transistor with both Light-ON and Dark-ON outputs, 5 to 24 V DC Supply voltage, Infrared LED, 1-meter, 4-core cable, IP64

The Panasonic PM-L45-P is a U-shaped, through-beam photoelectric sensor from the PM-45 series, designed for industrial automation applications. It features a fixed 6mm sensing range and a PNP open-collector output.

Key specifications

• Sensor type: U-shaped (fork), micro photoelectric sensor
• Sensing method: Through-beam, which is an integrated emitter and receiver in a single housing.
• Sensing range: Fixed 6 mm.
• Minimum sensing object: 0.8 x 1.2 mm opaque object.
• Response time: 20 μs (light received) and 80 μs (light interrupted).
• Output: PNP open-collector transistor with both Light-ON and Dark-ON outputs. Maximum source current is 50 mA.
• Power supply: 5 to 24 V DC.
• Light source: Infrared LED with a peak emission wavelength of 855 nm.
• Protection rating: IP64, indicating high resistance to dust and splashing water.
• Cable: Comes with a 1-meter, 4-core cable.
• Indicator: An orange LED indicates when light is received.
• Material: The housing is PBT, and the display section is polycarbonate.
