Panasonic Sunx Photoelectric Sensor PM-R45 U-shaped Through-beam
U-shaped, compact through-beam sensor PM-R45 Through-beam Fixed 6mm Range Infrared LED
The Panasonic PM-R45 Photoelectric Sensor is a U-shaped, compact through-beam sensor designed for industrial automation applications. As a member of the PM-45 series, it features a fixed 6mm sensing range and an infrared LED. The PM-R45 is available with different output types, including NPN (PM-R45) and PNP (PM-R45-P).
Specifications
| Sensing method | Through-beam, U-shaped (fork) |
| Sensing range | Fixed 6mm |
| Minimum sensing object | 0.8 x 1.2mm opaque object |
| Light source | Infrared LED (peak wavelength: 855 nm) |
| Output type |
PM-R45: NPN open-collector PM-R45-P: PNP open-collector |
| Output operation | Includes two outputs: Light-ON and Dark-ON |
| Supply voltage | 5 to 24V DC |
| Ingress protection | IP64 |
| Response time | Light received: 20µs or less Light interrupted: 80µs or less |
| Operation indicator | Orange LED that lights up when receiving light |
| Cable | 1m 4-core PVC cabtyre cable |
| Operating temperature | -25 to +55 °C |
| Housing material | Enclosure: PBT Display section: Polycarbonate |
Features
- High durability: The sensor is resistant to vibrations and impacts due to the resin covering on the connecting sections of the cable and internal circuit.
- Wide viewing indicator: The large orange operation indicator is easily visible from above and the sides, making it easy to confirm the sensor's status.
- Easy adjustment: Beam marks on the front and back of the sensor simplify alignment with the sensing object.
- Compact design: The sensor's U-shaped design and small size allow for mounting in tight spaces.
