Panasonic PM2-LF10 Photoelectric Sensor

Panasonic PM2-LF10 Convergent Reflective Photoelectric Sensor with Built-in Amplifier

The Panasonic PM2-LF10 is an ultra-small, convergent reflective photoelectric sensor with a built-in amplifier. It uses an infrared LED light source to detect objects in a limited area, making it less affected by background objects. The PM2-LF10 is the connector-type model.

Specifications

• Sensing method: Convergent reflective
• Sensing range: 2.5 to 8 mm, with a convergence point at 5 mm
• Minimum sensing object: ø0.05 mm copper wire
• Output: NPN open-collector transistor
• Response time: 0.8 ms or less
• Supply voltage: 5 to 24 V DC
• Light source: Infrared LED (880 nm)
• Operation indicator: Red LED
• Overcurrent protection: Incorporated
• Enclosure material: Polycarbonate
• Vibration and shock resistance: Built to withstand demanding industrial environments.
