IFM Pressure Sensor PN7092

IFM Pressure Sensor with Display PN7092 PN-100-SER14-QFRKG/US/ /V 18 to 30V DC; (to SELV/PELV) Operating voltage, 2x PNP/NPN-NO/NC Output, Relative Reading

Specification/Additional Details

• Type : Relative
• Suitable Media : Liquids
• Brand : IFM
• Part Number : PN-100-SER14-QFRKG/US/ /V
• Pressure Range : 0 to 100bar
• Accuracy : ±0.5 %

• Response Time : <3ms (Minimum Switching Output)

• Output : 2x PNP/NPN-NO/NC

• Supply Voltage : 18 to 30V DC

• Interface : I/O Link
• Housing Material : PBT GF20, PBT+PC GF30, PC, Stainless Steel

• Process Connection : G1/4

• Operating Temperature : -25°C to 80°C

• IP Protection Class : IP65, IP67

• Electrical Connection : M12 Connector

• Maximum Current : 150 mA @ +60  DegreeC, 200 mA @ +60  DegreeC, 250 mA @ +40  DegreeC
