PN7094 IFM Sensor
Product characteristics
| Number of inputs and outputs | Number of digital outputs: 2 | |||
| Measuring range |
|
|||
| Process connection | threaded connection G 1/4 internal thread |
Application
| Special feature | Gold-plated contacts | |||
| Measuring element | ceramic-capacitive pressure measuring cell | |||
| Application | for industrial applications | |||
| Media | liquids and gases | |||
| Medium temperature[°C] | -25...80 | |||
| Min. burst pressure |
|
|||
| Pressure rating |
|
|||
| Vacuum resistance |
|
|||
| Type of pressure | relative pressure; vacuum |
Electrical data
| Operating voltage[V] | 18...30 DC; (to SELV/PELV) |
| Current consumption[mA] | < 35 |
| Min. insulation resistance[MΩ] | 100; (500 V DC) |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time[s] | < 0.3 |
| Integrated watchdog | yes |
Inputs / outputs
| Number of inputs and outputs | Number of digital outputs: 2 |
Outputs
| Total number of outputs | 2 |
| Output signal | switching signal; IO-Link; (configurable) |
| Electrical design | PNP/NPN |
| Number of digital outputs | 2 |
| Output function | normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 150; (200 (...60 °C) 250 (...40 °C)) |
| Switching frequency DC[Hz] | < 170 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Measuring/setting range
| Measuring range |
|
| Factory setting / CMPT = 2 | ||||
|---|---|---|---|---|
| Set point SP |
|
|||
| Reset point rP |
|
|||
| Min. difference between SP and rP |
|
|||
| In steps of |
|
