Pogo Pin P125-G2 Test Probe

Gold plated Tip Test Probe P125-G2 Pogo Pin PCB test Probe Length 33.35mm Dia 2.02mm Head Dia 2.5m, P125-G2 spring test probe P125-G2 Test pin P125-G2 Test tool 33.35mm 2.02mm Needle gold tip Ø 2.50mm Pogo pin

The P125 Series, P125-G2 is a type of spring test probe, also known as a pogo pin, used for conducting tests on printed circuit boards (PCBs).

Specifications

• Model series: P125
• Model: P125-G2
• Head/Tip style: Flat
• Overall length: 33.35 mm.
• Probe tube diameter: 2.02 mm.
• Probe head diameter: 2.5 mm.
• Minimum test spacing: 3.18 mm.
• Construction: Gold-plated phosphor brass for durability and corrosion resistance.

• In-Circuit Testing (ICT): For making temporary, reliable connections to test points on a PCB to verify its electrical properties.
• Terminal and component testing: The flat head makes it suitable for testing flat pads, as well as accessing terminals and component leads.
• Test Fixtures: These probes are commonly used in custom-built test fixtures to test multiple points on a board at once.
