PPT-125B POWER MODULE

PPT-125B POWER MODULE
Technical Specifications

• Power Rating: ~99.5W to 100W with natural convection cooling; up to 124.46W with 18CFM forced air cooling. [
• Input Voltage: 90V AC to 264V AC (47–63Hz) or 127V DC to 370V DC.
• Outputs:
  • Output 1: +5V DC
  • Output 2: +12V DC
  • Output 3: -12V DC []
• Dimensions: Miniature 3 x 5 inch open-frame footprint. [
• Operating Temperature: -20°C to +70°C (with output derating at higher temperatures). []

Features & Protections

• Built-in active Power Factor Correction (PFC) function complying with EN 61000-3-2.
• Protections against short circuits, overload, overvoltage, and overtemperature.
• High reliability and long life with built-in remote sense and LED power indicator.
