PRDT12-4DC inductive proximity sensor

PRDT12-4DC inductive  proximity sensor
Technical SpecificationsAccording to official product documentation fromthe key electrical and physical attributes include:

• Sensing Distance: 4 mm (with a standard 12×12×1mm iron target).
• Setting Distance: 0 to 2.8 mm.
• Installation Type: Flush (Shielded) mountable.
• Operating Voltage: 12–24 VDC (operating range 10–30 VDC).
• Control Output: DC 2-wire Normally Closed (NC).
• Response Frequency: 450 Hz.
• Current Consumption: Max. 0.6 mA leakage current.
• Environmental Protection: IP67 rated (dust and water-resistant).
• Operating Temperature: -25°C to 70°C.
• Housing Material: Nickel-plated brass barrel with a heat-resistant ABS sensing face.
• Status Indicator: Built-in red LED for operational status tracking
