PRK5.M3/4P(50128201) Polarized Retro-reflective Photoelectric Sensor

PRK5.M3/4P(50128201) Polarized Retro-reflective Photoelectric Sensor
Key Technical Specifications

• Operating Range: Guaranteed range of 0.02 to 4.5 meters, with a typical limit of up to 6 meters when used with a TK(S) 100x100 reflector.
• Switching Output: Dual PNP transistor outputs (Output 1: Light switching; Output 2: Dark switching).
• Performance: Rapid 1 ms response time and a switching frequency of 500 Hz.
• Electrical: Operates on 10–30V DC supply voltage with polarity reversal and short-circuit protection.
• Mechanical:
  • Housing: Compact cubic design (14 x 32.5 x 20.2 mm) made of durable ABS plastic.
  • Connection: Features a 2000 mm 4-wire cable connection.
  • Durability: Rated IP 67 for dust and water resistance, suitable for washdown environments.
• Configuration: Includes a teach button for simplified setup and adjustment.
