FOTEK Inductive Proximity Switch PS-05PB Sensor

Fotek Sensor PS-05PB Inductive, 5 mm Sensing Range, PNP, Normally Closed (NC), Square-Shaped

The Fotek PS-05PB inductive proximity sensor is a square-shaped, DC-powered sensor with a 5 mm sensing range that uses a PNP, normally closed (NC) output. It is designed for industrial automation applications.

Key Specifications

• Sensing Distance: 5 mm
• Output Type: PNP (sourcing), Normally Closed (NC)
• Operating Voltage: 10–30 V DC (features short circuit and reverse polarity protection)
• Housing Shape: Square
• Body Material: PBT plastic
• Connection Type: Cabled (3 wires, 2m length)
• Protection Class: IP-67 (high solid compact structure suited for poor circumstances)
• Standard Sensing Object: Metals
• Operating Temperature/Humidity: -20°C to +80°C; 35% to 95% RH
