Nidec Components Corporation PS30-102R-N-030 Pressure Sensor

PS 30-102R-N-030 DC12-24V Pressure Switch Sensor NPN - Open Collector ±14.5PSI (±100kPa) Female - M5 Threaded Port ±200PSI (±1378.95kPa) Maximum Pressure -10°C ~ 50°C Operating Temperature ±1% Accuracy

Specification/Additional Details

• Suitable Media : Air

• Brand : Nidec Components Corporation

• Part Number : PS30-102R-N

• Accuracy : ±1%

• Output : NPN - Open Collector
• Supply Voltage : 12V ~ 24V
• Housing Material : Plastic
• Operating Temperature : -10°C ~ 50°C
• Port Size : Female - M5

• Port Style : Threaded

• Maximum Pressure : ±200PSI (±1378.95kPa)

• Operating Pressure : ±14.5PSI (±100kPa)

• Pressure Type : Compound
