PZ-M31P KEYENCE Sensor
Key Specifications

• Type: Intelligent reflective cable-type sensor
• Output: PNP (100 mA max control output), switch-selectable LIGHT-ON / DARK-ON
• Detecting Distance: 5 to 300 mm (using 100 x 100 mm white mat paper)
• Setting Distance: 40 to 300 mm
• Light Source: Red LED
• Response Time: 1 ms maximum
• Power Supply: 12 to 24 VDC (30 mA max current consumption)
• Sensitivity Adjustment: 1-turn trimmer (230°)
• Enclosure Rating: IP67
• Operating Temperature: -20 to +55 °C
• Material & Weight: Glass-fibre reinforced plastic housing, approx. 55 g
• Certifications: CE, UL (c/us)

If you need help with wiring diagrams, mounting accessories, or alternative models (such as the NPN version PZ-M31), let me know how your system is set up.
