Keyence PZ-M51 Photoelectric Sensor

Keyence PZ-M51 Photoelectric Sensor Thru-Beam, Square Transmissive Cable Type, NPN, 10 m Detecting distance, 1-turn trimmer (230°) Sensitivity adjustment, Red LED, LIGHT-ON/DARK-ON (switch-selectable), 12 to 24 VDC ±10 % Supply Voltage, IP67
with Built-in Amplifier PZ-M51 PZ-V/M Series Thru-Beam Photoelectric Sensor

Specification/Additional Details

• Sensor Type : Through-Beam
• Brand : Keyence
• Model : PZ-M51
• Output : NPN
• Control output : 100 mA (24 V) max., Residual voltage: 1 V max
• Operation mode : LIGHT-ON/DARK-ON (switch-selectable)

• Detecting distance : 10 m

• Sensitivity adjustment : 1-turn trimmer (230 Degree)

• Light source : Red LED

• Response time : 1.5 ms max

• Supply Voltage : 12 to 24 VDC +-10 %, Ripple (P-P) 10 % or less

• Enclosure rating : IP67
