Keyence PZ-M51P Photoelectric Sensor

Keyence PZ-M51P Photoelectric Sensor Thrubeam, Square Transmissive Cable Type, PNP, 10 m Detecting distance, 1-turn trimmer (230°) Sensitivity adjustment, LIGHT-ON/DARK-ON (switch-selectable), Red LED, 12 to 24 VDC ±10 % Supply Voltage, IP67
Keyence Built-in amplifier Thrubeam Photoelectric Sensor PZ-M51P PZ-V/M Series

Specification/Additional Details

• Sensor Type : Through-Beam
• Brand : Keyence
• Model : PZ-M51P
• Output : PNP
• Detecting distance : 10 m
• Sensitivity adjustment : 1-turn trimmer (230 Degree)

• Operation mode : LIGHT-ON/DARK-ON (switch-selectable)

• Response time : 1.5 ms max

• Light source : Red LED

• Control output : 100 mA (24 V) max., Residual voltage: 1 V max

• Voltage Supply : 12 to 24 VDC +-10 %, Ripple (P-P) 10 % or less

• Case material : Glass-fibre reinforced plastic

• Enclosure rating : IP67
