Q64DAN Mitsubishi Digital-analog Converter Module

Name: Q64DAN Mitsubishi Digital-analog Converter Module
Brand: QYSMT
Availability: InStock

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Product variants

Quantity

Key Specifications

Attribute	Detail
Manufacturer	Mitsubishi Electric
Series	MELSEC-Q Series
Output Channels	4 points (channels)
Output Types	Voltage: -10V to +10V, 0V to 5V, 1V to 5V DC
	Current: 0mA to 20mA, 4mA to 20mA DC
Resolution	12-bit (digital input is 16-bit signed binary)
Conversion Speed	80 µs per channel
Isolation	Between I/O terminals and PLC power supply: Photocoupler isolation; Between analog output channels: Non-isolation
Power Supply	5V DC internal from the base unit (0.34A consumption) and 24V DC external power supply for analog output
Dimensions (WxHxD)	27.4 mm x 98 mm x 112 mm
Weight	Approx. 0.2 kg
