QRR0.01G (S&A MAKE ) 10GRAM automatic aerosol fire extinguishing device

QRR0.01G (S&A MAKE ) 10GRAM QRR0.01G (S&A MAKE ) 10GRAM automatic aerosol fire extinguishing device
Core Specifications

• Extinguishing Agent Mass: 10 grams.
• Protected Volume: Up to 0.1 cubic meters (m³) (some ultra-compact variants target 0.06 m³).
• Activation Temperature: Automatically triggers at 170°C to 175°C (via an integrated thermal cord/wire, requiring no external electricity or battery).
• Discharge Time: Super rapid suppression, fully discharging the aerosol in under 6 seconds (ranges between 2 to 15 seconds depending on the specific casing configuration).
• Service Life: Maintenance-free lifespan of 10 years.
• Agent Composition: Solid chemical compound primarily made of Strontium Nitrate and Potassium Nitrate (Sr(NO₃)₂ and KNO₃). [1, 2]

Primary ApplicationsBecause the S-type condensed aerosol leaves zero conductive residue and requires no piping, it is specifically designed to safely extinguish Class A (surface), B, C, and E (electrical) fires inside:

• Electrical panels, distribution boards, and MCB breaker boxes.
• Lithium battery packs and energy storage compartments.
• Server racks, telecom cabinets, and ATM machines.
• Vehicle engine bays.

Installation & Mount TypesThese units are typically manufactured in two configurations:

• DIN Rail Mount: Shaped similarly to a standard circuit breaker (often called a 1P DIN rail fire extinguisher) to clip directly onto standard 35mm equipment rails.
• Fire Sticker / Adhesive Mount: A flat, ultra-thin form factor that sticks directly to the inner ceiling or walls of an enclosure using 3M double-sided tape.

Are you looking to purchase this specific module, or do you need help calculating the number of units required for a specific enclosure or electrical cabinet size?
