QS18VP6LPQ5 Photoelectric sensor
Key Technical Specifications
- Sensing Mode: Polarized Retroreflective (requires a separate reflector).
- Sensing Range: Maximum distance of 3.5 metres (\(3500\text{ mm}\)).
- Supply Voltage: \(10\text{V}\) to \(30\text{V DC}\).
- Output Type: Complementary (SPDT) PNP outputs providing both Light-ON and Dark-ON functionality.
- Response Time: Fast output response time of 0.6 milliseconds.
- Sensing Beam: Visible red LED light source (\(630\text{ nm}\)).
- Adjustment: Manual adjustment via an onboard potentiometer.
Design and Environment
- Housing Design: Universal rectangular shape with a built-in \(18\text{ mm}\) threaded barrel mount.
- Enclosure Rating: IP67 and NEMA 6 rated, making it dust-tight and water-resistant.
- Connection Method: \(150\text{ mm}\) (\(6\text{ inch}\)) pigtail cable terminated with a 4-pin Euro-style M12 quick-disconnect connector.
- Status Indicators: \(360^{\circ }\) visible bright LEDs showing operating status (Green for power ON, Yellow for light sensed).
- Temperature Limits: Operates between \(-20^{\circ }\text{C}\) and \(+70^{\circ }\text{C}\)
