GG wire+wire Handel Thermouple 1M QY18112203

A "GG wire + wire handle Thermocouple 1M" is a K-type thermocouple with glass braid insulation and a 1-meter (1M) long flexible wire for easy handling. The "GG" insulation and a wound "handle" make it suitable for high-temperature applications where flexibility and safety are important.

GG wire insulation

• The "GG" insulation refers to a duplex fiberglass, or glass braid, insulation on the thermocouple wire.
• Temperature resistance: This type of insulation is designed for high temperatures, typically with a maximum service temperature of 482°C (900°F).
• Insulation function: The duplex insulation ensures that the two thermocouple wires do not make unintended contact, which would lead to inaccurate readings.

Wire handle

• The "wire handle" is often a wound or spooled wire manager that provides a convenient and safe way to handle the thermocouple, particularly when taking measurements in extreme environments.
• Purpose: It allows the user to safely and accurately measure the temperature of objects from a distance.
