Spring Test Probe Receptacle R035-C Needle Pogo Pin Connect Socket

Test Pin Socket R035-C Needle Sleeve for Pogo Pin Female Socket Connector

The R035-C is a spring test probe receptacle, also known as a sleeve or socket, designed to hold and allow for easy replacement of a compatible test probe. It is primarily used in PCB (Printed Circuit Board) testing and other electronic testing applications.

• Purpose: The receptacle provides an easy way to replace a spring test probe after it has reached the end of its lifespan or become damaged.
• Material: The receptacle is often made of high-quality materials like brass with gold plating to ensure excellent conductivity and durability.
• Application: It is an essential component for conductive and in-circuit testing, accessing components on a PCB to test stability and functionality.

Dimensions and specifications

• Receptacle Length: 14mm.
• Probe Diameter: 0.45mm.
• Termination Types: Test probe receptacles generally feature various termination types for connecting to the test equipment, such as wire-wrap, solder cup, or crimp.
