R100-2W Pogo Pin Receptacle
R100-2W Pogo Pin Receptacle
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Spring Test Probe Receptacle R100-2W Needle Tube Socket Sleeve
Needle Sleeve R100-2W Receptacle For Pogo Pin, Test Pin Socket R100-2W Pogo Pin Holder
The R100-2W Pogo Pin Receptacle is a gold-plated, brass tube receptacle that is part of the P100 series of test components. Designed for durability and ease of use, it is a key component for creating a secure, wire-wrapped test connection for P100 pogo pins.
Specifications
- Overall Length: 39 mm
- Needle Sleeve Diameter: 1.67 mm
- Mounting Hole Diameter: 1.7 mm
- Wire-wrap Post Length: 9 mm
- Collar Height: 2.5 mm
- Collar Diameter: 1.83 mm
- Connection Type: Wire-wrap
- Material: Brass tube, gold-plated
Features
- Replaces Pins Easily: The receptacle holds the pogo pin, allowing for easy replacement when the spring wears out, without needing to desolder the entire connection.
- Secure Wire-Wrap Connection: The wire-wrap post provides a reliable and stable connection for testing purposes.
- Enhanced Conductivity: The gold-plated brass construction ensures excellent signal transmission.
- Broad Compatibility: The receptacle is designed to be used with the P100 series of test probes, which are available in various head shapes.
- Versatile Applications: It is often used in data communication equipment, PCB board testing, and prototyping.
