Receptacle R125-2S Pogo Pin Holder

Test Probe Needle Cover Gold Plated R125-2S Receptacle pin 2.36mm Dia 30mm Length Test Pin Holder, P125 series pogo pins cover R125-2S replacement cover for pogo pins, PCB Test Probe Pogo Pin Socket R125-2S Test Pin Socket Brass Tube Needle Sleeve ...

The R125-2S is a solder-type pogo pin receptacle used to create removable and reliable connections on a printed circuit board (PCB). A pogo pin (P125 series) is inserted into the receptacle, allowing for easy mating and de-mating for testing, programming, or other applications.

Working

The receptacle is a cylindrical component designed to be soldered directly onto a PCB or test bed. The open end allows a corresponding pogo pin to be press-fit and held securely in place, while the other end is soldered to a wire or connection point. This creates a robust yet discrete connector for repeatedly plugging and unplugging pogo pins.

• Receptacle type: Female socket.
• Connection type: Solder.
• Length: 30mm
• Receptacle Dia.: 2.36mm
• Mating pin series: Designed for use with P125 series pogo pins.
• Application: Commonly used in test jigs for in-circuit testing (ICT) and functional circuit testing (FCT).
• Functionality: Enables easy replacement of pogo pins when they reach the end of their service life.
• Durability: Provides a reliable and durable connection, functioning for a minimum of 100 insertion/extraction cycles.
• Conductivity: Offers good conductivity and stability.
• Material: Made from gold-plated brass for high performance.
