Spring Test Probe Needle Tube R160-2W Brass Needle Sleeve Pogo Pin

Gold Plated Pogo Pin Cover R160-2W Solder Connect Probe Spring Test Needle Tube Diameter 1.67mm Total Length 32.7mm ...

The R160-2W is a pogo pin receptacle used for creating a stable, temporary electrical connection, most often in circuit board testing. The "R" in the model name indicates it is a receptacle, while "160" refers to the series, and "-2W" indicates a specific variant within that series. The receptacle is designed to hold a spring-loaded test probe (pogo pin), which is inserted to make contact with a test point on a printed circuit board (PCB).

Key specifications

• Model number: R160-2W
• Purpose: Test probe receptacle
• Dimensions:
  • Length: 32.7 mm
  • Barrel diameter: 1.67 mm
• Mounting hole diameter: 1.70–1.75 mm
• Minimum test distance: 2.54 mm
• Materials:
  • Barrel: Brass
  • Finish: Gold-plated
• Connection type: Solder connection
