R2000-8-WB3W AIR REGULATOR

R2000-8-WB3W AIR REGULATOR
Core Specifications

• Working Fluid: Compressed air
• Port Size (-8): 1/4" (Rc, NPT, or G depending on configuration)
• Max Working Pressure: 1.0 MPa (approx. 10 bar / 150 psi)
• Set Pressure Range: 0.05 to 0.85 MPa (approx. 0.5 to 8.5 bar)
• Ambient / Fluid Temperature: 5°C to 60°C
• Suffix B3W: Denotes specific bracket/attachment options or integrated gauge configurations standard toordering nomenclature.

Key Features

• Embedded Gauge: Space-saving design with a built-in pressure indicator face.
• One-Push Locking: Easy adjustment mechanism requiring no extra locking tools.
• Relief Type: Includes a built-in relief mechanism to vent secondary overpressure safely.
