R50-2S Receptacle Pogo Pin
R50-2S Receptacle Pogo Pin
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
Spring Test Probe Receptacle R50-2S Needle Pogo Pin Connect Socket
Test Pin Socket R50-2S Needle Sleeve for Pogo Pin Female Socket Connector
An R50-2S receptacle is a solder-type connector used for printed circuit board (PCB) testing, not a standard wall outlet for household wiring. It holds a spring-loaded test probe (known as a pogo pin) and is used in in-circuit testing (ICT) and functional circuit testing (FCT) jigs.
Key characteristics
- Purpose: The receptacle acts as a holder for the P50 series test probes, which can be quickly inserted and replaced as needed for testing electronic components on a PCB. This design is used to extend the life of a testing station.
- Connection type: The R50-2S is designed for a solder connection, allowing it to be permanently attached to a testing fixture.
- Construction: The component is a gold-plated brass tube, offering good conductivity, stability, and durability.
-
Dimensions: It is a miniature connector with the following specifications:
- Total length: 17.5 mm
- Outer diameter: 0.86 mm
- Mounting hole diameter: 0.9 mm
- Electrical specifications: The R50-2S has a current rating of 3 amps.
