Omron R88M-KE20030H-BS2 AC Servo Motor

Omron R88M-KE20030H-BS2 G5 Series AC Servo Motor 200V AC 200W 0.64-1.91 Nm Torque 3000RPM Incremental Encoder with Brake

Specification/Additional Details

• Type : AC
• Voltage : 200V
• Brand : Omron
• Model Name/Number : R88M-KE20030H-BS2
• Torque : 0.64-1.91 Nm
• Product Type : Servo Motor
• Servo control method : Analog, EtherCAT, MECHATROLINK II, Pulse train

• Drive supply voltage : 230 V single phase

• Rated output : 0.2 kW

• Rated speed : 3000 r/min

• Rated torque : 0.64 Nm

• Peak torque : 1.91 Nm

• Encoder type : Incremental

• Motor with brake : Yes

• Flange size square (LC) : 60 mm

• Shaft diameter : 11 mm
