RAM1A60D125Z Solid State RELAY

RAM1A60D125Z  Solid State RELAY
Key Specifications

• Type of Relay: 1-Phase Solid State Relay (SSR)
• Switching Mode: Zero Cross (activates when AC voltage crosses zero)
• Load Current Rating: Up to 125 A
• Operational Load Voltage: 42 V to 660 V AC
• Control Voltage Range: 4 V to 32 V DC
• Output Component: Back-to-back thyristors (antiparallel thyristor output)
• Housing Design: Standard "Hockey Puck" shape with an IP20 clip-on touch-protection cover
• Termination Type: Screw terminal with captive clamp

Understanding the Model Code BreakdownThe alphanumeric part number corresponds to specific functional attributes outlined

• RAM: Product series identifier for industrial single-phase SSRs.
• 1A: Indicates a single-pole, zero-cross switching configuration.
• 60: Denotes the maximum rated operational load voltage range (up to 600V/660V AC).
• D: Specifies a DC control input voltage range (4-32 VDC).
• 125: Highlights the maximum rated load current capacity of 125 Amperes.
• Z: Specifies the inclusion of full overvoltage or specialized transient protection networks.
