RD-65A MW SMPS

RD-65A MW SMPS
Key Technical Specifications

• Outputs: Dual output providing 5V DC at 6A (Channel 1) and 12V DC at 3A (Channel 2).
• Total Power: Rated for a maximum of 66 Watts.
• Input Range: Supports a universal AC input of 88~264 VAC or 125~373 VDC.
• Efficiency: Typically operates at 79% efficiency.
• Dimensions: Compact metal chassis measuring 129 x 98 x 38 mm ( inches).
• Protections: Built-in safeguards against short circuits, overloads, and over-voltages.

Performance Features

• Durability: Features  long-life electrolytic capacitors and can withstand a 300 VAC surge for 5 seconds.
• Operating Conditions: Functional in temperatures ranging from  to  and can withstand up to 5G vibration.
• Cooling: Uses free air convection for cooling, meaning it has no moving parts (fans) thcould fail.
• Installation: Designed for chassis mounting using screw terminal blocks for electrical connections.
