RIKO RN04-N Inductive Proximity Sensor

RIKO RN04-N Rectangular Inductive Proximity Sensor 5mm Sensing Distance, NPN Normally Open (NO), 10-30 VDC Operating Voltage, ≤8 mA (no load) Current Consumption, 100 mA Control Output, 2ms Max. Response Time, -20°C to +60°C Operating Temperature, IP64, ABS resin or metal Housing Material, Pre-wired cable, 34.0 x 18.0 x 18.0mm (LxWxH) Body Dimensions.

Specification/Additional Details

• Sensing Distance : 5mm
• Usage : for Industrial
• Output : NPN
• Switching Function : Normally open (NO)
• Dimension : 34.0 x 18.0 x 18.0mm (LxWxH)
• Brand : Riko

• Model : RN04-N

• Type : Inductive proximity sensor

• Operating Voltage : 10-30 VDC

• Output Type : NPN Normally Open (NO). It functions as a 3-wire sensor (Brown: VCC, Blue: GND, Black: Output)

• Current Consumption : <8 mA (no load)

• Control Output : 100 mA

• Response Time : 2ms Max.

• Operating Temperature : -20°C to +60°C

• Housing Material : ABS resin or metal

• Connection Method : pre-wired cable 3-wire
