RKC4.5T-5/TXL Proximity sensor

RKC4.5T-5/TXL Proximity sensor

Number of pins 4Contacts Brass, CuZn, Gold-platedContact carriers Plastic, TPU, BlackConnector body Plastic, TPU, BlackCoupling nut/screw Brass, CuZn, Nickel-platedSeal Plastic, FPM/FKMMechanical lifespan > 100 Mating cyclesPollution degree 3Protection class IP67, IP69K, Only in screwed conditionCableCable diameter Ø 4.5 mm ±0.20Cable length 5  mCable jacket PUR, BlackCore insulation PPCore cross-section 4 x 0.34  mm²Arrangement of strands 42 x 0.1 mmCore colors BN, WH, BU, BKElectrical properties at +20 °CRated voltage 250 VTest voltage 2000 VCurrent 4 AInsulation resistance > 30.5 MΩ/kmforward resistance max. 57 Ω/km
