Spring Test Probe Receptacle RL50-2S Needle Pogo Pin Connect Socket

Test Pin Socket RL50-2S Needle Sleeve for Pogo Pin Female Socket Connector

The RL50-2S socket is a receptacle or sleeve used for holding and connecting a spring test probe. It is commonly used for electrical conductive testing and in test fixtures to create a stable, durable connection for circuit board testing.

Technical specifications

• Function: Holds a test probe so that it can be easily replaced if damaged or worn out, extending the life of a test station.
• Length: 26.8 mm.
• Outer diameter: 0.86mm.
• Materials: Phosphor bronze barrel with gold plating.
• Current rating: 3A.
