Spring Test Probe Needle Sleeve RL75-3S Pogo Pin Receptacle
R75-3S Pogo Pin Receptacle Solder Type Female socket Connector PCB Test Probe, RL75-3S Test Pin Needle Sleeve, Spring Test Probe Sleeve RL75-3S Receptacle, Needle Cover RL75-3S Probe Sleeve Probe Cover ...
The RL75-3S is a solder-type receptacle for a spring test probe, also known as a pogo pin. It is used in electronics manufacturing and testing to make temporary electrical connections to a printed circuit board (PCB).
Specifications
- Purpose: To insert a spring-loaded test probe (specifically the P75 series) and enable its quick replacement when damaged or worn.
- Connection type: Solder connection.
- Materials: The body is made of brass and gold-plated for enhanced conductivity and corrosion resistance.
-
Dimensions:
- Total length: 30 mm.
- Outer diameter: 1.32 mm.
- Collar diameter: 1.50 mm.
- Collar height: 5.0 mm.
- Mounting hole diameter: 1.40 mm.
- Current rating: 3A.
- Key feature: The receptacle itself does not contain a spring.
Applications
The RL75-3S receptacle is widely used in test fixtures and jigs within the electronics industry. Its applications include:
- In-Circuit Testing (ICT): Testing individual electronic components on a populated PCB.
- Functional Circuit Testing (FCT): Verifying the overall functionality of an electronic circuit.
- Quality assurance: Providing a reliable and durable connection point for repeated testing cycles.
- Prototyping: A convenient and flexible connection solution for a wide range of electrical projects.
