Spring Test Probe Needle Sleeve RL75-3W Pogo Pin Receptacle

Pogo Pin Receptacle RL75-3W Test Pin Needle Sleeve, Spring Test Probe Sleeve RL75-3W Receptacle, Needle Cover RL75-3W Probe Sleeve Probe Cover ...

The RL75-3W is a test probe receptacle, a sleeve-like component designed to hold a spring-loaded "pogo" test pin. it uses a wire-wrap connection method on the bottom for secure attachment.

• Purpose: To provide an easy and reliable way to replace individual test probes in electrical test fixtures, such as those used for testing printed circuit boards (PCBs).
• Materials: Made from phosphor bronze (brass with a gold-plated coating for superior conductivity and corrosion resistance).
• Dimensions:
  • Outer Diameter: 1.32 mm.
  • Total Length: 38.2 mm.
• Connections: The RL75-3W uses a wire-wrap connection, but other versions in the same series (like R75) may have solder (S) or terminal (T) connections.
• Compatibility: Designed to be used with the corresponding P75 series of spring test probes.
• Ease of maintenance: Allows for quick replacement of worn or damaged test pins without having to re-solder or re-wrap every time, extending the life of the test fixture.
