RMT20x250S AIRTAC

RMT20x250S AIRTAC
Key Specifications

• Bore Size: 20 mm
• Stroke Length: 250 mm
• Acting Type: Double acting
• Operating Pressure: 0.25 to 0.7 MPa (36 to 100 psi)
• Temperature Range: -20°C to 70°C
• Cushion Type: Fixed cushion (with rubber bumpers/adjustable pneumatic cushioning)
• Magnet: Includes magnet (indicated by the "S" suffix)

Features

• Space Saving: Rodless design uses a magnetically coupled external carriage instead of a traditional protruding piston rod.
• High Precision: Built with double guide rods to handle side loads and offset loads securely.
• Dust-Proof: The design isolates the external carriage from the internal piston tube.

If you need help with pricing, cad drawings, or compatible sensor switches for the RMT20x250S, let me know!
