Riko RN04-NP Inductive Proximity Sensor

Riko RN04-NP Rectangular Inductive Proximity Switch Sensor 5 mm Sensing Distance, NPN and PNP with both Normally Open (N.O.) and Normally Closed (N.C.) configurations, DC 10-30V Operating Voltage.

Specification/Additional Details

• Sensing Distance : 5 mm
• Usage : for Industrial
• Brand : Riko
• Model : RN04-NP
• Output Options : NPN and PNP, with both Normally Open (N.O.) and Normally Closed (N.C.) configurations
• Operating Voltage : 10-30V DC

• Current Consumption : <8 mA (no-load)

• Load Current : Up to 100 mA at DC 30V

• Response Time : 2ms max.

• Operating Temperature : -20°C to +60°C
