RP1072D-24F DIN Rail Switching Power Supply

RP1072D-24F DIN Rail Switching Power Supply

Core Specifications

• Manufacturer: Reign Power
• Output Power: 72 Watts max
• Output Voltage: +24 V DC (adjustable ±10%)
• Output Current: 3.0 Amperes
• Input Voltage: 100~240 V AC (Universal Input, 50-60Hz, 2.0A max)
• Efficiency: 80% Minimum
• Ripple & Noise: 150mVp-p

Physical & Installation Attributes

• Mounting Type: DIN Rail / Screw dual-purpose mounting.
• Dimensions: 100 mm (Height) x 110 mm (Depth) x 60 mm (Width).
• Weight: 430 grams.
• Wiring Connection: Barrier Terminal Block (typically designated with "T" for black or "E" for green block variants
