RSHN-2006 TDK LAMBDA

RSHN-2006 TDK LAMBDA
Key Specifications

• Rated Voltage: 250 VAC / 250 VDC.
• Rated Current: 6 Amperes.
• Mounting Type: Chassis mount (standard), with DIN rail options available (e.g., RSHN-2006D).
• Termination: Screw terminals with an open/close cover to simplify wiring and prevent lost hardware.
• Attenuation: Minimum 25 dB in the common mode frequency range of 0.2 MHz to 30 MHz.
• Operating Temperature: -25°C to +85°C.

Variant OptionsThe RSHN-2006 belongs to the broader RSHN series, which offers specific configurations:

• RSHN-2006D: Includes a DIN rail mounting bracket.
• RSHN-2006L: A low-leakage current version (max 1mA) suitable for medical or sensitive environments.
• RSHN-2006LD: Combines both DIN rail mounting and low-leakage characteristics.
