The RiKO RX Series U-Shape Photoelectric Sensors are engineered for precise detection in industrial environments. Their compact design and high-speed response make them ideal for applications requiring accurate sensing of small objects.

Key Features:

• High-Speed Response: Capable of detecting objects at speeds up to 2 kHz, ensuring quick and accurate detection.
• Compact Design: The U-shape configuration allows for easy integration into space-constrained areas.
• Visible Red Light Detection: Utilizes a 660 nm red LED for clear and reliable detection.
• Sensitivity Adjustment: Features a 12-turn potentiometer for precise sensitivity tuning.
• Durability: Built to withstand industrial environments with a protection degree of IP64.

Specifications:

• Sensing Distance: 6 mm
• Minimum Detection Object: Opaque object of Ø0.5 x 10.0 mm
• Emitting Light: Red LED, 660 nm
• Operating Voltage: DC12 ~ 24 V
• Current Consumption: 18 mA Max.
• Load Current: 100 mA Max. at DC24V
• Response Time: 1 ms Max.
• Ambient Illumination: Incandescent light: 1,000 lux max.
• Insulation Resistance: 20 MΩ min. (DC500V)
• Voltage Withstandability: AC500V 60Hz for 60 Sec.
• Operating Temperature: -10℃ ~ +55℃
• Protection Degree: IP64
• Material: PC
• Wiring Method: Pre-wired Ø4.2 x 2 M / 3-wires
• Weight: Approx. 55 g

Models Available:

• RX670-N: NPN output, dark-on mode
• RX670-P: PNP output, dark-on mode
• RX671-N: NPN output, light-on mode
• RX671-P: PNP output, light-on mode
• RX672-N: NPN output, light-on/dark-on mode
• RX672-P: PNP output, light-on/dark-on mode
• RX673-N: NPN output, DC-light type, dark-on mode
• RX673-P: PNP output, DC-light type, dark-on mode
• RX670-NW: NPN output, wide sensing distance
• RX670-PW: PNP output, wide sensing distance
• RX671-NW: NPN output, wide sensing distance
• RX671-PW: PNP output, wide sensing distance
• RX672-NW: NPN output, wide sensing distance
• RX672-PW: PNP output, wide sensing distance
• RX6730-NW: NPN output, wide sensing distance
• RX673-PW: PNP output, wide sensing distance

Applications:

• Automation: Ideal for monitoring and controlling processes in factories and plants.
• Robotics: Used for position and movement detection in robotic systems.
• Automotive: For detecting parts or objects during assembly.
• Packaging: To monitor and control packaging lines efficiently.
