RYH751F6-VV2-ZC1 Fuji servo drive

RYH751F6-VV2-ZC1 Fuji servo drive
Technical Breakdown of the Model NumberBased on Fuji Electric's coding system, the parts of the model number correspond to these specifications:

• RYH: Identifies the product as an ALPHA5 Smart Series Servo Amplifier.
• 751: Indicates the Applicable Motor Output (), which is 750W (or 500W).
• F: Refers to the series type, designed for speeds between 1500 to 3000 r/min.
• 6: The development order or version number.
• V (First 'V'): Major function code, indicating it supports Position, Speed, and Torque Control.
• V (Second 'V'): Upper interface code, signifying a General-purpose interface (supporting Pulse and Analog voltage).
• 2: Input voltage requirement, specifically 3-phase 200V (though some variants support 1-phase as well).
• ZC1: This suffix usually indicates a specific variation, such as a built-in braking resistor or a specific hardware revision for different regions.
