S-N50 AC110V Mitsubish magnetic contactor

S-N50 AC110V Mitsubish magnetic contactor

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

S-N50 AC110V Mitsubish magnetic contactor
Key Specifications

  • Poles: 3-poles (3P) main contacts
  • Control Coil Voltage: 100Vac–127Vac (supports 50Hz/60Hz, covering 110V applications)
  • Rated Current: 50A
  • Rated Power: 22kW at 440Vac (AC-3 IEC) / 30HP at 480Vac (3-phase UL)
  • Auxiliary Contacts: Typically configured with 2NO + 2NC auxiliary contacts
  • Mounting: DIN rail or surface mounting
  • Connections: Screw-clamp connections

Could you tell me what specific application or motor rating you plan to use this contactor for so I can verify if it matches your load requirements?
