S186EQ Banner Photoelectric Sensor Emitter

 S186EQ Banner Photoelectric Sensor Emitter
Core Specifications

• Sensing Mode: Opposed Emitter (through-beam).
• Sensing Range: Up to 20 metres (approx. 66 feet).
• Light Source: 950 nm Infrared (IR) LED.
• Supply Voltage: 10 to 30 V DC.
• Connection: 4-pin M12 "Euro-style" integral quick-disconnect (QD) connector.
• Housing: 18 mm threaded thermoplastic polyester barrel.
• Environmental Rating: IP67, IP69K, and NEMA 6P; suitable for high-pressure washdowns (up to 1200 psi).
• Operating Temperature: -40°C to +70°C (-40°F to +158°F).

Key Features

• EZ-BEAM Technology: Specially designed optics and electronics allow for reliable sensing without the need for manual adjustments.
• Dual-Indicator System: Features a green LED for power-on status and an amber LED that typically indicates output state in combined models, though emitters primarily use LEDs for power and performance monitoring.
• Durability: Fully epoxy-encapsulated housing provides superior resistance to harsh industrial environments.
• Protection: Includes circuitry to protect against reverse polarity and transient voltages.
