Manometer DMG S2610 Portable Digital Pressure Gauge

The Honeywell Kromschröder DMG S2610 manometer is a portable, digital pressure gauge designed for measuring positive, negative, and differential pressures of non-aggressive, dry gaseous media. It has a rated measuring range of up to ±1 bar (±1000 mbar) and is used in a variety of industrial, medical, and HVAC applications.

Key Specifications

Features

• Multiple Units: Measured values can be displayed in 8 different units, making it suitable for global use.
• Min/Max Values: The instrument automatically records and allows retrieval of minimum and maximum measured values during a measuring phase.
• Hold Function: A hold function is available to freeze the current measured value on the display.
• Automatic Zero Calibration: The device features automatic zero calibration for reliable measurements.
• Portability: It is a lightweight, handheld device with a robust protective sleeve and a magnet on the back for hands-free operation during adjustments.

Applications

The S2610 manometer is designed for mobile measurements in various fields:

• Burner Adjustment: Ideal for checking burner pressure and the gas/air ratio when adjusting gas burners.
• Tightness Tests: Used for conducting tightness tests in pipes.
• HVAC Systems: Suitable for air conditioning and ventilation system applications, such as filter inspection and measuring pressure loss in ducts.
• Laboratory & Industrial Use: Applications include pressure and vacuum measurements in a laboratory setting or process control on industrial furnaces.
