S310-202-H1DC Servo Drive Assay

S310-202-H1DC Servo Drive Assay
Technical Specifications BreakdownAccording to official product documentation from the part number breaks down as follows:

• S310: Inverter Motor Series.
• 202: 220V Input Supply Voltage / 2.0 Horsepower capacity.
• H: Standard specification type.
• 1: Single-Phase power supply.
• D: Built-in control keypad panel.
• C: Built-in RS-485 communication functionality.
• Output Rating: 1.5 kW (2 HP) continuous motor output.
• Enclosure Protection: IP20 rating.

Core Functional Features

• Control Method: Standard V/f control for basic torque and speed curves.
• Output Frequency Range: 0.01 to 400.0 Hz.
• Torque Capabilities: Auto torque boost capable of delivering up to 150% torque at 6 Hz.
• Programming & Interface: Features 8-speed setting profiles, independent acceleration/deceleration configurations, a 5-digit LED status panel, and full integration with automation networks using Modbus over the RS-485 interface.
