Datalogic S51-PA-5-C01-PK Photoelectric Diffuse Sensor

Datalogic Photoelectric S51-PA-5-C01-PK Long Diffuse Proximity Sensor PNP, NO & NC Output type, Red Laser 650 nm, 10 to 30V DC Supply Voltage, 500µs Response time, IP67

Specification/Additional Details

• Sensor Type : Diffused
• Brand : Datalogic
• Model : S51-PA-5-C01-PK
• Optic function : Diffuse Proximity
• Output type : PNP - Dark-ON/Light-ON
• Sensing distance : 0" ~ 27.559" (0mm ~ 700mm)
• Power supply : 10 to 30V DC

• Power consumption : 35 mA max

• Light emission type : Red Laser 650 nm

• Connection : Connector, M12

• Response time : 0.5ms

• Housing material : PBT, Nickel plated Brass

• IP Rating : IP67
