SANHWA MT-10 AC110V-DC99V brake rectifier module

SANHWA MT-10 AC110V-DC99V brake rectifier module
technical Specifications

• Brand: Sanhwa (also written as Sanxwa)
• Model: MT-10
• Input Voltage: AC 100V / 110V (50/60 Hz)
• Output Voltage: DC 90V / 99V

Wiring Diagram GuideThe label on the housing features a printed circuit schematic instructing how to attach the leads:

• AC Input Side: Connect the two white wires (labeled 白 白) directly to your AC 100V/110V power source.
• DC Output Side: Connect the red wire (labeled 红 for positive +) and the black wire (labeled 黑 for negative -) to the electromagnetic brake coil terminals
